CAMERAS
INTELLIO BOX ILD-510B
CAMERA COMPRESSION
Image Sensor Aptina 5MP 1/2.5” CMOS Progressive Scan Video Compression H.264 - Hierarhical P encoding
Sensitivity Day/Night: 0.65 lux / 0.01 lux Bit Rate
1/6s - 1/20,000s 500Kbps - 18Mbps
Shutter time True Streaming
Day/night mode Software Intellio Video Streaming, Dual streaming over
1/2.5” format, C/CS mount, DC iris, megapixel RTSP
WDR mode resolution
Lenses NETWORK
Protocols NTP, TCP/IPv4, DHCP, DNS
Security Camera User Name and Password
IMAGE MAIN FEATURES
Resolution 4:3: 2560x1920, 1920x1440, 1280×960; 640×480 • On-board VCA
Frame Rate 16:9: 2560x1440, 1920x1080, 1280x720, 640x360 • 5 megapixel sensor
Image Settings • Effective resolution: 2560×1920
H.264 4:3: 14fps (2560x1920), 22fps (1920x1440), 40fps (1280x960) • H.264 - Hierarhical P encoding
Encoder Settings H.264 16:9: 16fps (2560x1440), 30fps (1920x1080), 45fps (1280x720) • Camera-side bandwidth
Brightness, Contrast, Gamma, Saturation, Sharpness, Noise Filtering, White balance (5 presets), Operation mode (gain/exp preference), management
Exposure control, Gain control, Anti-flickering (50Hz/60Hz), Backlight compensation (adjustable zones), Software WDR mode, Day/Night
mode (Auto/Day/Night), Day/Night mode preference, Image Mirroring
Codec Type, Quality, I-frame Distance, Resolution, Frame Limit, Reduced Frame Rate Control, Bandwidth Limit, Pre- and Post-alarm
INTERFACE CAMERA SOFTWARE OPTIONAL ACCESSORIES AND LENSES
Ethernet 10BaseT/100BaseTX, RJ-45 Motion Detection 64 polygon per mask, 8 masks, All masks Power ILA-PS-12-H-EU
IO Ports 6 Pin IO Connector (1 Output (2 Pins), with adjustable sensitivity and motion percent supplies
parameters, Separated motion detector for LENSES
1 Input (2 Pins), GND, AUX Voltage) monitoring and for recording
Reset Button Reset To Factory Defaults (IP Address Reset) Lens type
SD-card slot Yes INTELLIGENT VIDEO Horizontal Vertical
SL940A view angle view angle
GENERAL Detectors Motion Detector M125VD4510- range range
Extended Intelligence Tampering detectors: Covering detection, IR
Operating Conditions 0 °C - 45 °C Rotation detection 26-7° 20-5°
Power Connector Screw Fixable Terminal Blocks | Accessory: Object Tracker IO port input detector
Power connector (DC jack 5.5mm/2.1mm) 73-33° 55-25°
Power Supply 12V DC (+2V, -3V), 650mA / PoE Support Tracker based detectors: Intelligent motion
(IEEE 802.3af - PoE Class 3) detection, Tripwire detection, Entry detection,
Direction detection
Power Consumption Max. 7,5W Object based detector: Object removal / theft
Weight 385g (without lens) detection
Certificates CE: EN 55022, EN 55024, RoHS compliant, FCC 64 polygon for masking, Object behavior settings,
compliant in progress Day-time/Night-time sensitivity, Environmental
settings
5 FULL HD H.264 POE ON-BOARD
RESOLUTION HIERARCHICAL P SUPPORT STORAGE ON
5 USB DRIVE
MEGAPIXEL SUPPORT
RESOLUTION
ON-BOARD ON-BOARD ITRACKING ISHOT
STORAGE ON PLAYBACK TECHNOLOGY TECHNOLOGY
SD CARD
